3.5 degree small circle with central point effect red laser (Model HW650XYQ100-16GD-3.5°)
At 0.5 meters, the circle is 31 millimeters in diameter
At 1 meter, the circle is 62 millimeters in diameter
Installation height 0 m - 5 m can be used
The whole set includes: laser head + stand +1-3V adjustable power supply
Output wavelength: 650nm (customizable)
Core power: 100mw (optional)
Operating voltage: DC 2.8V to 5.2V (customizable)
Working current: < 500mA
Dimensions: 16*70mm (customizable)
Optical lens: grating plate
Output type: power type
Speed: High speed
Channel: Single channel
Output wavelength: 650 (nm)
Advantages:
◆ Light is clear and bright, soft and not dazzling;
◆ Light thickness can be adjusted to meet your different requirements;
◆ The shell is aviation aluminum-plated insulating paint, which can not only fully dissipate heat,
but also anti-shock, anti-fall and anti-static;
◆ Imported laser diode direct light, especially high stability, can be open 24 hours a day;
◆ Intelligent driver board with imported IC, 2.8-5.2V ultra-wide range of power supply
(other voltages can be customized);
◆ High temperature and corrosion resistant DC plug wire,
suitable for all-weather environment;
◆ Wavelength, power, wire length, working distance, spot effect, etc.
can be customized according to customer requirements, you want, here!
