650nm Red Cross positioning light DC line laser module head High power bright laser module
- Product Item : B6305-GL
- Category：
Cross Laser module
- DC line laser module head
- 650nm Red Cross positioning light
- t DC line laser module head High power bright laser module
-
-
Cross-border parcel weight: 0.5kg
Unit weight: 0.5kg
Band range: visible light
Operation mode: continuous
Excitation mode: electric excitation type
Working material: semiconductor
Optical path: through external optical path
Output type: power type
Transmission signal: single power supply type
Speed: High speed
Output wavelength: 635 (nm)
Line width: ≤1 (mm)
Product name: Red grand cross positioning light
Exit pupil power: 3~100mw
Fan Angle: 90°~120%
Storage temperature: -40°C~85°C
Accessories: Industrial support laser, special power adjustment wrench
Model: LK-B6505-GL/+
Output: >1/5000
Operating temperature: -10°C~50°C
Optical system: optically coated glass lens
Spot pattern: crosshair
Wavelength: 650nm
Line width: The line width at 3M is less than 1.5mm
Input voltage: AC170~250V/DC3V
Dimensions: Phi 32mmx90mm
Service life: >8000H
